| Item | Parameter |
|---|---|
| Model Series | SUN-7K / 7.5K / 8K-G02P1-EU-AM2 |
| Inverter Topology | Non-isolated |
| Mounting | Wall-mounted |
| Protection Grade | IP65 |
| Cooling Mode | Natural cooling |
| Noise Level | ≤35dB |
| Operating Temp | -25℃ ~ +60℃, power derating above 45℃ |
| Humidity | 0–100% non-condensing |
| Max Altitude | 3000m |
| Dimension (W×H×D) | 330 × 310 × 208.5 mm |
| Net Weight | 12.1kg |
| Standard Warranty | 5 years |
| Certifications | IEC 61727, IEC 62116, EN 50549, CE & full EMC compliance |
| Item | SUN-7K | SUN-7.5K | SUN-8K |
|---|---|---|---|
| Max DC Input Power | 10.5kW | 11.3kW | 12kW |
| Max PV Voltage | 550V | 550V | 550V |
| Startup Voltage | 80V | 80V | 80V |
| MPPT Operating Range | 70–500V | 70–500V | 70–500V |
| Rated PV Voltage | 360V | 360V | 360V |
| Max Operating DC Current | 18+26A | 18+26A | 18+26A |
| Max DC Short Circuit Current | 27+39A | 27+39A | 27+39A |
| MPPT Quantity / Strings per MPPT | 2 / 1+2 | 2 / 1+2 | 2 / 1+2 |
| Item | SUN-7K | SUN-7.5K | SUN-8K |
|---|---|---|---|
| Rated AC Active Power | 7kW | 7.5kW | 8kW |
| Max AC Apparent Power | 7.7kVA | 8.25kVA | 8.8kVA |
| Rated Output Current | 31.9/30.5A | 34.1/32.7A | 36.4/34.8A |
| Max Output Current | 35/33.5A | 37.5/35.9A | 40/38.3A |
| Grid Connection | Single-phase L+N+PE, 220/230V 50Hz | ||
| Power Factor Range | 0.8 lagging ~ 0.8 leading | ||
| THDi (Rated Load) | ＜3% | ||
| DC Injection Component | ＜0.5% In |
DC reverse polarity protection, AC overcurrent/overvoltage/short-circuit protection, overheat protection, insulation resistance detection, DC component monitoring, anti-islanding protection, built-in DC switch, residual current detection, AFCI arc fault protection; Type II lightning surge protection on DC & AC sides.
